TUBO LED
Product Description
Aluminum injection body
GU10 type socket
Electrostatic powder coating paint
Optional body colors
ENEC Standards
IP20, IP44
Installation
Aluminum injection body GU10 type socket Electrostatic powder coating paint Optional body colors ENEC Standards IP20, IP44
Connection
DALI, DIM, DMX
Design
Reflector
PMMA Diffuser
Light distribution
Asymmetrical, Narrow beam, Wide beam
Specification
Versions
Documents
Technical Drawings
Specification
İnput Voltage:
220 V
IP Rate:
20
Impact Resistance:
09
CCT:
4000 K
Mounting Option:
Lightway:
Frame:
Beam Angle:
Direct
Control:
ON/OFF
Version Product Code
Version Power
Version CCT
Version Dimensions
Version Lumen
TUBO 7..X.70x70.N.X.X
7 W
4000 K
85 mm
880 lm
TUBO 10.X.70x70.N.X.X
10 W
4000 K
80 mm
1230 lm
TUBO 13..X.70x70.N.X.X
13 W
4000 K
80 mm
1580 lm
