CANDLE POLE V2
Product Description
Installation
Connection
Design
Lenses
Light distribution
Specification
Versions
Documents
Technical Drawings
Specification
İnput Voltage:
230 V
IP Rate:
66
Impact Resistance:
09
CCT:
2200, 3500, 4000, 6500 K
Beam Angle:
Asymmetrical, Direct, Symmetrical
Control:
DALI, DMX
Version Product Code
Version Power
Version CCT
Version Dimensions
Version Lumen
CANDLEPOLE.8.AC.N.4.1500.7016
8 W
4000 K
1500 mm
960 lm
CANDLEPOLE.10.AC.N.4.1500.7016
10 W
4000 K
2000 mm
1200 lm
CANDLEPOLE.15.AC.N.4.1500.7016
15 W
4000 K
2500 mm
1800 lm
CANDLEPOLE.20.AC.N.4.1500.7016
20 W
4000 K
3000 mm
2400 lm
CANDLEPOLE.20.AC.N.4.1500.7016
20 W
4000 K
4000 mm
2200 lm
CANDLEPOLE.20.AC.N.4.1500.7016
20 W
4000 K
5000 mm
2100 lm
