RICIO
Product Description
Aluminum injection body
Tempered glass
Constant current LED driver
Electrostatic powder coating paint
Optional body colors
ENEC Standards
Installation
RECESSED INSTALLATION IN THE CEILING DRIVER HOUSING IS SEPARATE FOR EASY INSTALLATION
Connection
ON/OFF- DALI- DIMMABLE 1-10V
Design
CIRCLE SHAPE FIXED DOWNLIGHT MADE OF ALUMINIUM IN WHITE COLOR AS STANDARD OPTION WITH PMMA DIFFUSOR
Reflector
Reflector of matt metallised aluminium in white color as standard
Light distribution
DIRECT BEAM ANGLE
Versions
Documents
Technical Drawings
Version Product Code
Version Power
Version CCT
Version Dimensions
Version Lumen
RICIO.7.70.N.4.19
7 W
4000 K
90X70 mm
770 lm
RICIO.7.70.N.4.40
7 W
4000 K
90X70 mm
750 lm
RICIO.10.70.N.4.19
10 W
4000 K
90X70 mm
1070 lm
RICIO.10.70.N.4.40
10 W
4000 K
90X70 mm
1050 lm
