ALTO MAG SYSTEM
Product Description
Aluminum extruded body
Adjustable length steel ropes
Nickel plated brass parts
Electrostatic powder coating paint
Production in different lengths
Optional body colors
ENEC standards
Glare Control Optical Lens
Installation
Aluminium body Aluminium extrusion heatsink Electrostatic powder coating paint High performance LED High efficiency reflector Optional body colors ENEC standards
Connection
ON/OFF- DALI- DIMMABLE 1-10V
Design
Aluminum injection body coating paint Optional body colors
Reflector
Glare Control Optical Lens
Light distribution
2700K, 3000K, 4000K,5000K, 6500K
Versions
Documents
Technical Drawings
Version Product Code
Version Power
Version CCT
Version Dimensions
Version Lumen
ALTO MAG 10.5.135.N.4.120
5 W
400 K
135 mm
550 lm
ALTO MAG 10. 10.135.N.4.120
10 W
4000 K
135 mm
1100 lm
ALTO MAG 10.10.270.N.4.120
10 W
4000 K
270 mm
1100 lm
ALTO MAG 10.20.270.N.4.120
20 W
4000 K
270 mm
2200 lm
ALTO MAG 10.15.400.N.4.120
15 W
4000 K
400 mm
1650 lm
ALTO MAG 10.30.400.N.4.120
30 W
4000 K
400 mm
4200 lm
