ELECTI ROUND ADJ 51
Product Description
Aluminum injection body
High efficiency reflector
Constant current LED driver
Electrostatic powder coating paint
Optional body colors
ENEC Standards
Installation
Aluminum injection body High efficiency reflector Constant current LED driver Electrostatic powder coating paint Optional body colors ENEC Standards
Connection
ON/OFF
Design
Reflector
PMMA Diffuser
Light distribution
Asymmetrical, Narrow beam, Wide beam
Specification
Versions
Documents
Technical Drawings
Specification
İnput Voltage:
220 V
IP Rate:
20
Impact Resistance:
CCT:
4000 K
Mounting Option:
Recessed, Pendant
Lightway:
INDIRECT
Frame:
Trimless
Beam Angle:
Asymmetrical, Narrow beam, Wide beam
Control:
ON/OFF
Version Product Code
Version Power
Version CCT
Version Dimensions
Version Lumen
ELCT RND ADJ 51.7.51.N.4.19
7 W
4000 K
mm
850 lm
ELCT RND ADJ 51.7.51.N.4.19
7 W
4000 K
mm
820 lm
ELCT RND ADJ 51.10.51.N.4.19
10 W
4000 K
mm
1140 lm
ELCT RND ADJ 51.10.51.N.4.19
10 W
4000 K
mm
1110 lm
ELCT RND ADJ 51.13.51.N.4.19
13 W
4000 K
mm
1390 lm
ELCT RND ADJ 51.13.51.N.4.19
13 W
4000 K
mm
1360 lm
