CESAR Tunable Wallwasher

Product Description

Cesar Family Tunable Wallwashers are designed to have high efficiency White Color Dynamic Solutions.  It is fully aluminum finish including end caps and stainless steel montage brackets. Can be aluminum as optional. It gives you Symmetric and Asymmetric optic lens options. Integrated power supply units provides easy installation and long term success. Both sides Cesar Wallwashers have Male and Female IP68 Connectors unders the products.Cesar Wallwasher designed to have Continuous connection to give great facade effects. It has IP67 Protection against to water and dust.

Cesar Tunable White Wallwashers have integrated / Built in power supply and DMX512 HB LUX Color Changing System Technologies inside of the body. Each product have own controller and it provides easy installation. Prefered to have most efficient White Colors high lumens. Product LED Color Temperature can be between 2200K-6500K. Up to project we can make built in system as remotely as well.

Installation

on/off Control (No Dimmable) Input Voltage 110-240V/AC Color Rendering Index >80 2700K-3000K-4000K-6500K Light Beam 12° / 20° / 34° / 45° / 60° / Asymm 3 / 3+3 pins Circular M19 Type DMX512 -30C°/+60C° Temperature Up to 4 channels Space address Automatic or Manual Control Philips, Osram, Cree, Samsung LED Chips Meanwell, Philips, Osram Power Supply Dimmable (OPTIONAL)

Connection

Design

Designed for architectural Dynamic White (DW) facade lighting (2700K-6500K) Linear Type Tunable Wallwasher Aluminum extrusion body Tempered Glass High Power LED High Efficiency Built-IN Power Supply Continouos interconnection with IP67 connectors Mounting bracket made of Stainless steel Power factor>90% full loading Production in different lengths Optional body colors ENEC Standards

Lenses

Light distribution

Specification

İnput Voltage:

230 V

IP Rate:

67

Impact Resistance:

CCT:

2700, 6500 K

Beam Angle:

Asymmetrical, Medium beam, Narrow beam, Symmetrical, Wide beam

Control:

Manual control
